Victron Cyrix-Li-Charge 24 / 48V 230A Intelligent Charge Relay

• Voltage: 24/48
• Continuous current & Breaking capacity at 12V or 24V: 230A
• Current Consumption When Open: 4 mA
• Control Cable Included: Yes (1m)
• LED Status Indication: Yes
• Protection Category: IP54
• Dimensions: 65 x 100 x 50mm
• Weight: 0.27Kg

The Cyrix-Li-Charge will connect a battery charger with 3 seconds delay:

• if the charge disconnect output of the VE.Bus BMS is high and
• if it senses 13.7 V (resp. 27.4 V or 54.8 V) or more on its battery charger connection terminal and
• if it senses 2 V or more on its battery terminal (the Cyrix will remain open if not connect to the battery).

The Cyrix-Li-Charge will disengage immediately whenever its control input becomes free floating signalling cell over voltage or cell over temperature.

In general a cell over voltage alarm will reset shortly after charging has been stopped. The Cyrix will then reconnect the charger after a delay 3 seconds. After 2 attempts to reengage with 3 seconds delay the delay increases to 10 minutes. Whenever battery voltage is less than 13.5 V (resp. 27 V or 54 V) the Cyrix will disengage with a delay of 1 hour.

Note: In case of zero discharge current or a small discharge current the Cyrix will not disengage shortly after the charger has been switched off and/or disconnected because battery voltage will remain higher than 13.5 V. If after the Cyrix has disengaged the output of the battery charger immediately increases to 13.7 V or more the Cyrix will reengage with 3 seconds delay.
